RadiLux Designer Radiator Horizontal White Flat Panel Rads Single Panel 600x604mm
Product details
Product information
Key Features: - Single flat panel design offering a sleek, modern aesthetic, ideal for spaces where minimal projection is desired. - Horizontally hung installation for easy retrofitting and efficient heat distribution. - Classic white finish that complements minimalist and contemporary interiors. - Constructed from premium mild steel for excellent thermal conduction and long-lasting durability. - Compatible with most domestic central heating systems with standard G1/2 inch inlet and outlet connections. - Comes complete with fixings and brackets for straightforward wall mounting. - Backed by a 10-year guarantee and complies with BS EN 442 standards. This modern designer radiator provides a stylish heating solution that marries functionality with aesthetic appeal. Its single panel design helps to minimise projection, making it perfect for hallways and smaller spaces while still delivering efficient warmth. The sleek white finish and horizontal orientation ensure that it complements both contemporary and traditionally retrofitted rooms. Crafted from premium mild steel, this radiator promises durability and outstanding thermal performance. The complete installation kit, including fixings and brackets, means you can enjoy a hassle-free setup. Please note that this radiator is not suitable for single pipe systems, and you will need to purchase radiator valves separately. Technical Specifications: - Dimensions: Height 600 mm; Width 605 mm; Depth 52 mm. - Projection from wall (including brackets): 83 mm. - Heat Output: BTU Output (Delta 50) 1430; Watts Output (Delta 50) 419; BTU Output (Delta 30) 743; Watts Output (Delta 30) 218; Watts Output (Delta 65) 586. - Pipe Centres: 604 mm (with a tolerance of 5 mm). - Tube Quantity: 8. - Weight: 10.0 kg. - Maximum Working Pressure: 4 bars; Maximum Working Temperature: 95°. - RAL Colour Code: 9016. - Installation Type: Hot Water; Inlet Connection: G1/2 inches; Wall to Centre Tapping: 50 mm.
- Non-adjustable
- Fittings & fixings included
- Comes with- Radiator & Fittings
- Guarantee - 15 years
Features and benefits
- High-quality designer radiator with a stunning white finish.
- Compact size of 600 x 604mm, suitable for various spaces.
- Single flat panel design for a sleek appearance.
- Constructed from low-carbon steel for durability.
- Scratch- and rust-resistant for long-lasting performance.
- Compatible with all tank-fed and combination heating systems.
- Includes a fantastic FREE 15-year guarantee.
Specifications
| BTU | 1430BTU |
|---|---|
| Coating | Powder-coated |
| Colour | White |
| Finish | Gloss |
| Fitting type | Wall-mounted |
| Heat output | 419W |
| Inlet position | Bottom |
| Material | Mild steel |
| Maximum operating pressure | 4bar |
| Maximum operating temperature | 95°C |
| Model name/number | RadiLux |
| Number of columns | 8 |
| Outlet position | Bottom |
| Product depth | 52mm |
| Product height | 600mm |
| Product weight | 10kg |
| Product width | 600mm |
| Projection from the wall | 83mm |
| Radiator type | Designer |
| Thermostatic control | Without thermostat |
| Orientation | Horizontal |
| Product code | 5056806139593 |
